Manitowoc Published 03-29-17, Control # 064-23 v2 4-43
14000 OPERATOR MANUAL SETUP AND INSTALLATION
7. Slowly raise mast only enough to align bottom connector
holes in butt with bottom connector holes in insert
(View F).
8. Remove pins (14, View G) from storage and pin boom
butt to insert.
9. Unpin pendants (7, View F) from lifting lugs on boom butt
and pin pendants to storage lugs (8, View M) on mast
(2).
10. Connect mast straps to boom straps:
a. Remove pins (17, View N) from boom straps (16).
b. Remove pin (19, View N) from both storage
brackets.
c. Rotate strap storage links (18, View N) to the
working position (View L).
d. Install pins (19, View L) to secure the strap storage
links (18) in working position.
e. Position mast so holes in mast straps (15, View L)
are aligned with proper holes in boom straps (16).
f. Install pins (17, View L).
NOTE: When performing following steps, thoroughly clean
ends of hydraulic hoses, couplers, cable plugs, and
receptacles before connecting them.
11. Disconnect electric cable (WBC, View B, Figure 4-8
)
from terminating plug on right-front corner of rotating
bed. Attach dust cap to terminating plug.
12. Connect electric cable (WBC, View H) to electric cable
(20) from cable reel in boom butt.
13. If equipped with Drum 3 in boom butt, proceed as
follows:
a. Remove dust caps from couplers (21, View K).
b. Remove dust caps from couplers on four hydraulic
hoses (22, View K) in boom butt.
c. Connect hydraulic hoses (22) to couplers (21).
d. Connect electric cable(s) (W34API and W33API,
View J) from Drum 3 to receptacles on front of
rotating bed.
14. Install wind speed indicator assembly if removed for
shipping. Use star washers to attach mounting bracket
to boom top to provide a good ground (see Wind Speed
Assembly drawing at end of this section).
Connect electrical cable WWCB at base of wind speed
mounting bracket.
15. Lower mast arms using switch in operator’s cab.
16. Select proper capacity chart on configuration screen of
RCL display.
17. Boom can now be raised. Perform Pre-Raising
Checks.
Legend for FIGURE 4-21 continued
CAUTION
Boom Butt Damage!
Avoid overload damage to boom butt:
• Do not allow bottom connectors in butt to bottom out
against bottom connectors in insert while performing
step 7
• Do not continue to boom up after bottom connector
pins are installed
WARNING
Moving Part Hazard!
Prevent serious crushing injury:
• Do not stand inside boom while installing connector
pins — STAND OUTSIDE BOOM
DANGER
Falling Mast/Boom Hazard!
Prevent mast and boom from falling:
• Fully lower mast arms before raising boom. Mast can
buckle and collapse if it contacts mast arms with
a fully rigged boom
Item Description Item Description
1 Boom Butt 18 Strap Storage Link
2 Mast 19 Pin with Cotter Pin
7 Pendant 20 Electric Cable from Cable Rel
8 Storage Lug 21 Hydraulic Couplers
12 Insert 22 Hydraulic Hoses
14 Pin with Safety Pin W34API Electric Cable from Drum 3
15 Mast Strap W33API Electric Cable from Drum 3 Bail Limit
16 Boom Straps (on first insert) WBC Electric Cable from Engine Node
17 Pin with Collar, Retaining Pin and Cotter Pins
To Next Page
