14000 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
Table 3-2 Bypassable Limit Identification Past Production Model 14000
This Table Applies to Cranes Equipped With Luffing Jib Limit Bypass Switch (D5)
Limit
Past Production Console
Limit
Bypass Switch (D4)
(momentary)
Luffing Jib Limit
Bypass Switch (D5)
1
(maintained)
Boom Maximum Up No No
Boom Down (optional) Yes No
Block-Up (each drum) Yes Yes
Bail, Max and Min (each drum) Yes No
Luffing Jib Maximum UP 1 Yes Yes
Luffing Jib Maximum UP 2
Yes
2
Yes
2
Luffing Jib Maximum Down 1 Yes No
Luffing Jib Maximum Down 2 No No
Rated Capacity Limiter Yes Yes
Mast Too Far Forward No No
1
Fault 6 alarm will remain on when this switch is in bypass position.
2
Only when boom is below 50°
