Grove Published 7-23-2020, Control # 668-02 4-91
GRT9165 OPERATOR MANUAL OPERATING PROCEDURES
Additionally, the main and auxiliary hoist indicators can have
the following status:
Name Symbol Description
Main Hoist Raise
Indicator (Green)
Indicates the main hoist rope is being reeled in.
Main Hoist Lower
Indicator (Green)
Indicates the main hoist rope is being let out.
Main Hoist High Speed
Indicator (Green)
Indicates the main hoist function and the high speed function are enabled.
Auxiliary Hoist Raise
Indicator (Green)
Indicates the auxiliary hoist rope is being reeled in.
Auxiliary Hoist Lower
Indicator (Green)
Indicates the auxiliary hoist rope is being let out.
Auxiliary Hoist High
Speed Indicator (Green)
Indicates the auxiliary hoist function and the high speed function are enabled.
