Grove Published 7-23-2020, Control # 668-02 4-95
GRT9165 OPERATOR MANUAL OPERATING PROCEDURES
Item Description Page Item Description Page
1 Tele-automation Menu Group Icon 4-96 20
Telescope Recovery Mode Icon -
Resetting Telescope Configuration
4-46
2 Semi-automatic Telescope Mode Icon 4-96 21 Faults Menu Group Icon 4-144
3 Boom Configurator Mode Icon 4-98 22 Crane Faults Icon 4-144
4 Crane Function Menu Group Icon 4-100 23 Engine Faults Icon 4-145
5 Outrigger Extend/Retract Icon 4-100 24 Information Menu Group Icon 4-146
6 Counterweight Removal/Installation Icon 4-106 25 Operating Hours Icon 4-146
7 360° Superstructure Lock/Unlock Icon 4-106 26 Software Versions Icon 4-148
8 Boom Extension Deployment/Stowage Icon 4-107 27 Legal Notice Icon 4-148
9 Suspension Raise/Lower Icon 4-107 28 User Settings Menu Group Icon 4-149
10 Boom Removal/installation Icon 4-108 29 Controller Curve Icon 4-149
11 WRL Menu Group Icon 4-110 30 Controller Speed Icon 4-152
12 Swing Angle Limitation Icon 4-124 31 ECO Mode Icon 4-153
13 Boom Angle Limitation Icon 4-119 32 Exhaust System Cleaning Icon 4-155
14 Boom Height Limitation Icon 4-117 33 Service Menu Icon 4-156
15 Radius Limitation Icon 4-122 34 Screen Settings Menu Group Icon 4-157
16 Virtual Walls Icon 4-127 35 Units of Measure (Metric/Imperial) Icon 4-157
17 Emergency Program Menu Group Icon 4-131 36 Display Screen Brightness Icon 4-157
18 Manual Telescope Mode Icon 4-131 37 Time Set Icon 4-158
19 Emergency Telescope Mode Icon 4-133
