Grove Published 7-23-2020, Control # 668-02 4-101
GRT9165 OPERATOR MANUAL OPERATING PROCEDURES
Item Description Item Description
1 Left Front Beam/Jack 7 Inclination Indicator
2 Right Front Beam/Jack 8 Menu Screen Icon
3 Right Rear Beam/Jack 9 O/R Beams Icon
4 Left Rear Beam/Jack 10 O/R Jacks Icon
5 Percentage Outrigger Beam is Extended 11 O/R Jacks x4 Icon
6 Steering Wheel (to indicate front of crane) 12 Auto-level Icon
FIGURE 4-97
9902-4
1 2
4
5
6
1 1
8
7
9
1 0
1 2
3
5
55
