Grove Published 7-23-2020, Control # 668-02 4-141
GRT9165 OPERATOR MANUAL OPERATING PROCEDURES
4
Table 4-1 Locking point distances for telescopic boom sections
T1 (mm) T2 (mm) T3 (mm) T4 (mm) T5 (mm)
0% 0 280 539 798 1033
55%50% 5363 5664 5481 5714 5959
92% 8660 8974 9312 9525 9778
100% 9727 10045 10393 10600 10855
Table 4-2 Locking point distances for telescoping cylinder
T1 (mm) T2 (mm) T3 (mm) T4 (mm) T5 (mm)
0% 0 280 539 798 1033
55%/50% 5333 5634 5451 5684 5929
92% 8630 8944 9282 9495 9748
100% 9697 10015 10363 10570 10825
