MAINTENANCE AND LUBRICATION GRT9165 OPERATOR MANUAL
6-40 Published 7-23-2020, Control # 668-02
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Approximate
Capacity
Service Interval
Service
Application
Boom Lubrication (Continued)
42
Tele 5 Rear Upper
Wear Pad
Figure 6-20 N
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 47.
43
Tele 4 Rear Upper
Wear Pad
Figure 6-20 N
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 47.
44
Tele 3 Rear Upper
Wear Pad
Figure 6-20 N
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 47.
45
Tele 2 Rear Upper
Wear Pad
Figure 6-20 N
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 47.
46
Tele 1 Rear Upper
Wear Pad
Figure 6-20 N
Only until
resistance
is felt
Every 500 hours, or
6 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 47.
47
Tele 1 Lock Pin Figure 6-20 P
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 48.
48 Tele 2 Lock Pin Figure 6-20 P
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 48.
49 Tele 3 Lock Pin Figure 6-20 P
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 48.
50 Tele 4 Lock Pin Figure 6-20 P
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 48.
51 Tele 5 Lock Pin Figure 6-20 P
1 or 2 pumps
each fitting
Every 250 hours, or
3 months, whichever
interval comes first
LUBRICATE
2 service points
See NOTE 48.
NOTE 47: DO NOT apply excessive pressure or force when greasing wear pads. Applying excessive pressure or force
can cause grease fitting to separate from wear pad. Apply grease only until resistance is felt.
NOTE 48: To grease rear upper-wear pads, front wear pads, and locking pins on each Tele Section, follow the boom Tele
Section positioning and lubrication instruction given in the section titled READ FIRST! IMPORTANT CRANE
SET-UP INFORMATION!, page 6-36. Start with Tele Section 5 (Tele 5). See also your GRT9165 Service Manual
for detailed service interval and specified boom lubrication instructions.
