MAINTENANCE AND LUBRICATION GRT9165 OPERATOR MANUAL
6-42 Published 7-23-2020, Control # 668-02
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Approximate
Capacity
Service Interval
Service
Application
Boom Lubrication (Continued)
52
Tele Cylinder
Wear Pad
Figure 6-21 N
Coat areas
that the wear
pads move on
Every 500 hours, or
6 months of service,
whichever interval
comes first
BRUSH ON
5 service points
53
Boom Extension
Pivot Pin
Figure 6-21 A
Until grease
extrudes
Every 100 hours, or
1 month of service,
whichever interval
comes first
LUBRICATE
2 service points
54 Mast Sheave Figure 6-21 — —
Every 250 hours, or
3 months of service,
whichever interval
comes first
CHECK
1 service point
CHECK sheave
for dry points of
operation
CHECK sheave
for grease leaks
See NOTE 49.
55
Boom Nose
Sheave
Figure 6-21 — —
Every 250 hours, or
3 months of service,
whichever interval
comes first
CHECK
7 service points
CHECK sheave
for dry points of
operation
CHECK sheave
for grease leaks
See NOTE 49.
56
Auxiliary Boom
Nose Sheave
Figure 6-21 — —
Every 250 hours, or
3 months of service,
whichever interval
comes first
CHECK
1 service point
CHECK sheave
for dry points of
operation
CHECK sheave
for grease leaks
See NOTE 49.
57
Boom Extension
Offset Cylinder
Pivot Pin
Figure 6-21 A
Until grease
extrudes
Every 100 hours, or
1 month of service,
whichever interval
comes first
LUBRICATE
2 service points
