FIGURE 4-65
Target Beam Height
Maximum Beam HeightMinimum Beam Height
Item Description
1 Mast Strap Tension
2 Operator’s Screen
3 Machined Surface
4 Arrow Decal
5 Alignment Decal
6 Stop Block
