SET-UP AND INSTALLATION MLC650 VPC-MAX™ OPERATOR MANUAL
4-142
Published 04-06-18, Control # 231-14
Moving the Actuator Pinions out of Mesh
See Figure 4-119 for the following procedure.
1. Attach the two plates and four pendants from the
counterweight tray to the assist crane and to the
actuator (1).
NOTE: Any additional rigging used between the assist
crane hook block and plates must not exceed
3,6 m (12 ft) in length.
2. Using the assist crane, hoist just enough to remove the
slack from the pendants.
NOTE: Do not hoist the actuator off the rotating bed. The
actuator must still be supported by the rollers.
3. Using the remote control, move the actuator back until
the pinions (2) are no longer in mesh with the rack
teeth (3).
FIGURE 4-119
Item Description
1 Actuator
2 Pinion (qty 2)
3 Rack Teeth
