MAINTENANCE MLC650 VPC-MAX™ OPERATOR MANUAL
6-12
Published 04-06-18, Control # 231-14
VPC-MAX CALIBRATION
Calibrating the VPC-MAX Actuator
Calibrate the actuator in the VPC-MAX Calibration Screen of
the Main Display.
See the Main Display Operation Manual for detailed
instructions under the topic VPC-MAX Calibration at
Installation.
Calibrating the Counterweight Tray
Calibrate the counterweight tray in the VPC-MAX calibration
screen.
See the Main Display Operation Manual for detailed
instructions under the topic VPC-MAX Calibration at
Installation.
Item Description
1 VPC-MAX Right Side Beam-on-Hook Limit Switch
2 VPC-MAX Left Side Beam-on-Hook Limit Switch
3 VPC-MAX Right Side Beam Up Limit Switch
4 VPC-MAX Left Side Beam Up Limit Switch
5 VPC-MAX Beam In Limit Switch.
6 VPC-MAX Beam Out Limit Switch.
7 VPC-MAX Tray In Limit Switch.
8 VPC-MAX Tray Out Limit Switch.
9 VPC Tray In Limit Switch.
10 VPC Tray Out Limit Switch.
Limit Switch TRIPPED
Limit Switch NOT TRIPPED
FIGURE 6-9
