Manitowoc Published 04-06-18, Control # 231-14 2-3
MLC650 VPC-MAX™ OPERATOR MANUAL SAFETY INFORMATION
Table 2-2 Miscellaneous Symbols
SAFETY AND INFORMATION SIGNS
Maintaining Signs
The crane owner/user shall make sure that all safety and
information signs are legible and installed at the proper
locations on the crane. If a sign has been defaced or
removed, it must be replaced immediately. See the
Nameplate and Decal Drawing at the end of this section for
the installation locations of signs.
Ordering Signs
Order replacement safety and information signs from your
Manitowoc dealer.
When ordering a sign, give the crane model number, the
crane serial number, and the name and part number of the
sign.
Emergency Cab Exit
Table 2-1 Common Safety Symbols
Diesel Fuel Engine Coolant
Engine Coolant
Vent
Engine Oil Level Hydraulic Filter Hydraulic Oil
Pump Drive Oil
Level
Tire Pressure
(if equipped)
