MLC650 VPC-MAX™ OPERATOR MANUAL MAINTENANCE
6
FIGURE 6-12
View A—PAST
Item Description
1 Rotating Bed
2 VPC-MAX Beam
3 10 mm (13/32 in)
4 Rotating Bed Pin (qty 2)
5 Beam Hook (qty 2)
6 Beam Up Limit Switch (qty 2)
7Bracket
8 6 mm (1/4 in)
9a Beam-on-Hook Limit Switch (qty 2) PAST
9b Beam-on-Hook Limit Switch (qty 2) CURRENT
10 Bracket (qty 2)
11 Limit Switch Tripping Bracket (qty 2)
View B—PAST
View A—CURRENT
View B—CURRENT
Both Sides of Rotating Bed
