SET-UP AND INSTALLATION MLC650 VPC-MAX™ OPERATOR MANUAL
4-24
Published 04-06-18, Control # 231-14
FIGURE 4-25
Item Description
1 Beam Up Limit Switch (qty 2)
2 Beam-on-Hook Limit Switch (qty 2)
3 Limit Switch Tripping Bracket (qty 2)
4 VPC-MAX Beam Assembly
5 Lifting Lug (qty 4)
