SET-UP AND INSTALLATION MLC650 VPC-MAX™ OPERATOR MANUAL
4-40
Published 04-06-18, Control # 231-14
FIGURE 4-38
Item Description
1 Counterweight Tray
2Actuator
3 Stop Block (qty 2)
4 VPC-MAX Calibration Screen
View C
Minimum Working Position
of Counterweight Tray
View B
Counterweight Tray
Calibration Position
View A
