5B-790-13645--2 495 LOWER UNIT
Exhaust Plate Components (Continued)
TORQUE
REF. NO. QUAN. DESCRIPTION lb. in. lb. ft. N·m
1 1 Exhaust Plate
2 3 Dowel Pin
3 1 Lower Cowl Seal
4 1 Upper Mount
5 4 Bolt – Upper Mount to Exhaust Plate 23 31.2
6 2 Bolt – Upper Mount
7 2 Spacer – Upper Mount Bolt
8 2 Washer – Upper Mount Bolt
9 2 Nut – Upper Mount Bolt 80 108.5
10 3 Bolt – Exhaust Plate 15 20.3
11 1 Gasket – Exhaust Plate
12 1 Exhaust Tube
13 2 Bolt – Exhaust Tube to Plate 15 20.3
14 1 Seal – Lower Exhaust Tube
15 1 Water Tube
16 1 Clamp – Water Tube Seal
17 1 Seal – Upper Water Tube
18 2 Bolt – Water Tube Clamp 80 9.0
19 1 Grommet – Water Tube
20 1 Bracket – Lower Cowl
21 1 Seal – Lower Cowl Bracket
22 3 Bolt – Lower Cowl Bracket 23 31.2
23 1 Shift Shaft Bushing
24 1 Upper Shift Shaft
25 1 Shift Shaft Bushing
26 1 Shift Link
27 1 Wave Washer – Shift Shaft
28 1 Washer – Shift Nut;
29 1 Lock Nut – Shift Shaft; No Torque Requirement - Drive Unit Tight, But
Joint Must Be Free To Pivot
30 1 Shift Shaft Spacer
31 1 Shift Shaft Coupling – Non-Power Trim
32 1 Shift Shaft Coupling – Power Trim
33 1 Water Tube Extension
34 1 O-Ring – Extra Long Shaft Only
35 1 Seal – Extra Long Shaft Only
