90-13645--2 495 1-3GENERAL INFORMATION AND SPECIFICATIONS
Cowl Removal
Pull outward on starboard side of front shield (a).
Remove spring (b) from latch and open cowls.
18291
a
18292
b
Filling Oil Injection System
Open starboard cowl (refer to cowl removal on this
page). Some earlier outboards will have a cowl brack-
et to hold cowl open as shown.
Fill tank with recommended oil.
a
a - Oil Tank Tube
