Series F Test Frames + IntelliMESUR
®
Software User’s Guide
2 SAFETY
Safety features provided by Series F test frames may be impaired if equipment is used in a
manner not specified by Mark-10.
2.1 Checks and procedures
The following safety checks and procedures should be performed before and during operation:
1. Always consider the characteristics of the sample being tested before initiating a test. A risk
assessment should be carried out beforehand to ensure that all safety measures have been
addressed and implemented.
2. Wear eye and face protection when testing, especially when testing brittle samples that have the
potential to shatter under force. Be aware of the dangers posed by potential energy that can
accumulate in the sample during testing. Extra bodily protection should be worn if a destructive
failure of a test sample is possible.
3. Keep away from moving parts of the test frame. Loose articles of clothing should not be worn.
Long hair should be covered to avoid a hazardous situation. A Crush Hazard warning label is
located on the base of the test frame. It appears as follows:
Definition: Keep any body parts and clothing clear of the area between the base of the test frame and the
moving crosshead.
4. Ensure that grips and fixtures are positioned to ensure axial load with respect to the load axis of
the force sensor.
Ensure that they secure the sample in such a way that it is prevented from
slipping out during a test, which is a safety risk to the operator and others in the vicinity. If using a
grip or fixture from a supplier other than Mark-10, ensure that it is constructed of suitably rugged
materials and components.
5. In those applications where samples can shatter, or other applications that could lead to a
hazardous situation, use of a safety shield is strongly recommended.
6. When the test frame is not in use, ensure that the power is turned off to prevent accidental
engagement of any of the controls.
2.2 Connecting power
Plug one end of the power cord into its receptacle at the rear of the stand and the other end into a wall
outlet with local earth ground (3-prong connector).
Before turning on power, the following safety checks and procedures should be performed:
1. Never operate the test frame if there is any visible damage to the power cord or the test frame
itself. The test frame is powered by 110V/220V. Any contact with this high voltage can cause
serious injury or even death.
