14.3 Installing a double column extension – F105 / F305 / F505
Models AC1095-1 / -2 / -3 column extensions are shipped fully assembled. To mount the test frame to the
assembly, locate the 6 thru holes, match them up to the corresponding threaded holes on the underside
of the frame, and install the screws. Refer to the image below:
x6
