3. Attach the top flange to the bottom of the test frame column utilizing the 6 supplied screws, as
shown in the image below:
4. Position the test frame vertically and reinstall the sheet metal covers, as shown below:
Vertical column extensions present an increased tipping hazard. It is strongly recommended
that the base be fastened to a workbench utilizing the holes on the underside of the base.
Refer to the dimensional drawing for hole locations.
x6
