Series F Test Frames + IntelliMESUR
®
Software User’s Guide
2. Ensure that the test frame is kept away from water or any electrically conductive liquids at all
times.
3. Make sure the electrical outlet powering the test frame has local earth ground (3-prong
connector).
4. The test frame should be serviced by a trained technician only. Power must be disconnected
before the column covers are removed.
5. Never use a detachable mains supply cord with inadequate ratings.
After the above safety checks and procedures have been performed, the test frame may be powered on
and is ready for operation.
2.3 Emergency Stop
The emergency stop switch is located where the lower right end of the column is attached to the base, as
shown below:
Models F105 / F305 / F505 / F505H Models F755 / F755S / F1505 / F1505S
Press down to stop crosshead motion. Rotate clockwise to release the switch.
