16 SPECIFICATIONS & DIMENSIONS
16.1 Specifications
F105
F305
F505
F505H
F755
F755S
F1505
F1505S
Load capacity*:
100 lbF
[0.5 kN]
300 lbF
[1.5 kN]
500 lbF
[2.2 kN]
750 lbF
[3.4 kN]
1,500 lbF
[6.7 kN]
Maximum travel:
18.0 in
[457 mm]
32 in
[813 mm]
14.2 in
[360 mm]
32 in
[813 mm]
14.2 in
[360 mm]
Speed range:
0.02 – 45 in/min
[0.5 – 1,100 mm/min]
0.001 - 60 in/min
[0.02 - 1,525 mm/min]
0.001 - 70 in/min
[0.02 - 1,800 mm/min]
Load accuracy
(% of full scale):
Test frame: ±0.1%
Force sensor: Series FS05: ±0.1% | Series R07: ±0.15%
Load sampling
rate:
20,000 Hz
Data acquisition
rate:
1,000 Hz
Speed accuracy:
±0.2% of setting, virtually no variation with load
Distance
accuracy:
±0.002 in / 0.05 mm, factory-compensated at up to full load
Distance
resolution:
0.0005 in / 0.01 mm
Limit switch
repeatability:
±0.001 in [0.03 mm]
Power: Universal input 100-240 VAC, 50/60 Hz, 300W
Universal input 100-240
VAC, 50/60 Hz, 120W
Universal input 100-240
VAC, 50/60 Hz, 450W
Fuse type:
1.2 A, 250V, 3AG, SLO BLO 4A, 3AG, SLO BLO
Weight:
60 lb
[27 kg]
70 lb
[32 kg]
184 lb
[83 kg]
149 lb
[68 kg]
197 lb
[89 kg]
157 lb
[71 kg]
Environmental
conditions:
- Indoor use only
- Up to 6,500 ft [2,000 m] above sea level
- Temperature range: 40 - 95°F [5 - 35°C]
- Humidity range: up to 80% relative humidity at 31°C, decreasing linearly to 50% relative humidity at
40°C, non-condensing
- Mains supply voltage fluctuations up to ±10 % of the nominal voltage
- Transient overvoltages up to the levels of Overvoltage Category II
- Use in environments up to Pollution Degree 2
Conformance:
CE
Warranty:
3 years [see individual statement for further details]
* Load capacity is reduced at higher speeds in the following models:
- F305: limited to 200 lbF [1 kN] above 24 in [610 mm]/min
- F505 / F505H: limited to 300 lbF [1.5 kN] above 24 in [610 mm]/min
- F755 / F755S: limited to 500 lbF [2.3 kN] above 35 in [900 mm]/min
- F1505 / F1505S: limited to 1,000 lbF [4.5 kN] above 60 in [1,525 mm]/min
