1 OVERVIEW
1.1 Intended purpose
Series F test frames produce tension and compression forces. When combined with a force sensor and
IntelliMESUR software, users can measure force and distance, set up a test, record, analyze, and output
data. Test frames are offered in several models, corresponding to different heights and force ranges.
Series FS05 or Series R07 force sensors are required for use with these test frames.
IntelliMESUR software is required to run Series F test frames and extract force and distance data from
the test frame and force sensor. IntelliMESUR is offered pre-configured on a tablet with mounting bracket,
or as a standalone software application which may be installed on the user’s device.
1.2 Models F105 / F305 / F505 / F505H
1.2.1 Included items
Qty.
Description
1
Control panel, mounting bracket, and hardware (-IMT models only)
1
Mounting bracket, column end (F505H only)
1
USB flash drive containing software installation files (-IM models only)
1
USB dongle (-IM models only)
1
USB cable
-IMT models: right-angle C to B
-IM models: A to B
1
Accessories kit:
- #10-32M medium hook
- 5/16-18M large hook
- #10-32F 2” diameter compression plate
- #10-32 M/F 2” extension rod
- #10-32 F/F coupler
- Adapter, 5/16-18M to #10-32F
- Set screw, #10-32 x 3/4" (1)
- Hex nut, #10-32 (2)
- Allen wrench set
1
Power cord
1
Allen wrench set
