Series F Test Frames + IntelliMESUR
®
Software User’s Guide
6
TOC 
1.2.3 Installing the Column End Cap for F505H
The end cap is shipped in a separate box within the main box for the F505H test frame. Line it up with the
right end of the column, then install with the four included screws, as shown below:
1.3 Models F755 / F755S / F1505 / F1505S
1.3.1 Included items
Qty.
Description
1
Control panel, mounting bracket, and hardware (-IMT models only)
1
USB flash drive containing software installation files (-IM models only)
1
USB dongle (-IM models only)
1
USB cable
-IMT models: right-angle C to B
-IM models: A to B
1
Eye end kit for base
2
Lock ring for eye end
2
Spanner wrench
1
Power cord
1
Allen wrench set
