Series F Test Frames + IntelliMESUR
®
Software User’s Guide
Note: Overloads which may occur while the force sensor is disconnected from a Series F test frame, or
while the test frame is powered off, are not recorded in Overload History.
6.6 Deflection Compensation
Refer to the Calibration section for further information.
6.7 Update Software and Update Firmware
Refer to the Maintenance and Service section for further information.
7 MANUAL CONTROL
Manual Control allows the user to move the crosshead up and down and observe force and distance
data, without creating a test. Manual control is useful when needing to manually adjust the crosshead
prior to starting a test, and also provides a means of creating a reference point for Height Mode.
Note: Data cannot be saved in Manual Control.
The screen appears as follows:
