Catch Sensors | V1 | Introduction and Presentation
Data update rate V2: depth, catch: 2-3 sec. - temp, pitch,
roll, battery: 12-24 sec. - echogram: 1-2
sec.
V3: depth, catch: 4 sec. - temp, pitch, roll,
battery: 17 sec. - echogram: 1.5 sec.
Typical battery life Up to 19 hours †
Standard: 6-8 hours ‡
Charging time
Fast Charge: 2.5 hours
Battery type Lithium-Ion
Weight in air 5 kg
Weight in water 0.9 kg
Warranty 2 years (Sensor & Battery) **
*Reference only. Depends on functions enabled. / † Depends on sensor uplink power
and options. / ‡ Based on average charging time. / **Marport Standard Marine Limited
Warranty
Catch Explorer Beamwidths
Beamwidths for Uplink pings
Beamwidth @ 35 kHz @ 50 kHz @ 60 kHz
-3dB 46° 40° 30°
Beamwidths for Down pings
@ 360 kHz
-3dB 13°
| 14
