Replacing the Pressure Sensor
Replacing the Pressure Sensor
Before you begin
Before installing, check on the end cap that there is the following pressure-relief symbol.
It shows that your sensor has a pressure-relief spring.
To replace the pressure sensor, you need a pressure sensor replacement kit containing:
• Install tool
• Washer (only if pressure-relief spring)
• Pressure sensor
• Small O-ring
• Adapter ring
• Screw
• Pressure-relief spring (if applicable)
You also need the following tools:
• 6 mm Allen key
• 1.5 mm Allen key
• 1/8" Allen key
• Flat screwdriver size 8 to 10
• Tweezers
• Wire stripper
• Crimping tool
• O-ring lubricant
• Loctite 425
About this task
Only qualified Marport technicians can do this task.
| 77
