Catch Sensors | V1 | Servicing and Maintenance
8.
From the tab Depth, click Depth coefficients.
9.
Click Browse and select the xml file you downloaded.
10.
Click Apply.
The pressure coefficients are updated.
Replacing the Transducer
Before you begin
For this task you need the following tools:
• 6 mm Allen key
• 1/8" Allen key
• Needle nose pliers
• O-ring lubricant
About this task
Only qualified Marport technicians can do this task.
Procedure
1.
To remove the housing of the sensor: remove the screws on each side of the end cap
using a size 6 Allen key, then push the bottle out.
| 84
