Matrox Extio 3 Series – User Guide 15
 Set Power recovery policy to Always start ( Transmitter  Settings  More options ).
This will allow the remote units to power up and return to a usable state.
 The Routing scheme defaults to Unicast ( Transmitter  Settings  Streaming ).
Note: This only needs to be done if your setup does not support Multicast packets
(for example, GRE tunnels).
7 Log into your receiver and switch to different transmitters (OSD) – see “Using the OSD
(On-Screen Display)”, page 64.
Typical bandwidth requirements
The bandwidth required is typically as specified in the following table:
Networked-Internet with IPSec VPN mode
In the Networked-Internet with IPSec VPN mode, Extio 3 receivers operate on a secure connection
over a virtual private network. The Active Directory authentication will be available in this mode.
Do the following to operate your Extio 3 units over internet with IPSec VPN:
1 Install your card – see “Installing your Extio 3 transmitter card”, page 28.
Resolution per stream Target bit rate (quality)
Bandwidth per stream
(Mbps)
*
* Note: This is for a single video stream including audio and USB HID.
1920 x 1080 @ 60 Hz Low 15
Typ ical 30
1920 x 1200 @ 60 Hz Low 16.5
Typical 33.1
3840 x 2160 @ 30 Hz Low 25
Typ ical 50
3840 x 2160 @ 60 Hz Low 50
Typ ical 10 0
Note: The Networked-Internet with IPSec VPN mode is only available on the receiver. The
transmitter will just react to the VPN connection request but will not activate VPN mode
like the receiver.
Note: To ensure best performance of the VPN, we recommend that you use a solid
background color in the Windows host configuration.
