INSTALLATION 3 - 6
D-MAXE with OI-TSwww.maxcessintl.com MI 2-292 1 C
Montage.fm
Electrical connection
CAUTION:
Electrical connections on the D-MAXE system should always be
made or disconnected while there is no electrical power in the
system.
Failure to follow these instructions may result in damage to
the D-MAXE system.
Emergency Stop Observe the “D-MAX Supplementary Operating Instructions -
Safe shutoff of electromechanical actuators driven by a D-MAX
or D-MAXE Controller” in the system documentation.
Power supply of D-MAXE
Controller The D-MAXE Controller has no power switch. Because of this,
the power supply of the D-MAXE Controller
must be switched on
and off via the machine's power distribution.
The D-MAXE Controller must be connected to the power supply
according to the information supplied at connector X6 of the
controller (see
figure 3.8
and
figure 3.10
).
Power supply of operator
interface OI-TS The power supply for the operator interface OI-TS is via the
signal cable, which is connected to the web guide controller at
connector X8.
Connecting the sensors/
actuators – Only sensors and actuators approved by Fife-Tidland GmbH
may be used.
– The technical data for sensors and actuators must match the
connection data for the D-MAXE system (see
Technical Data,
page 11-1
).
– Relevant operating instructions must be observed for
installation and operation of sensors and actuators.
– Sensors and actuators must be connected to the D-MAXE
system according to the system diagram in the system
documentation.
