TECHNICAL DATA11 - 2
D-MAXE with OI-TS www.maxcessintl.comMI 2-292 1 C
D-MAX operator interface
OI-TS Power supply
12 to 24V nominal
10V minimum to 30V maximum
Power consumption
2W
Dimensions
Wall mounting: 128 x 105 x 38mm [5 x 4.1 x 1.49 inches]
Desk installation: 128 x 105 x 33+5mm
Weight
0.6kg [1.3 lbs] (OI-TS only, without mounting accessories)
Protection class
IP64 according to DIN EN 60529
Ambient conditions
Ambient temperature: 0°C to 60°C [32 to 140°F]
Relative humidity: 10% to 95% non-condensing
Altitude above sea level: maximum 3000m [9842 ft]
Inputs and outputs of
the D-MAXE Controller Communication interface
based on Ethernet - 100Mbps full duplex
[Note 3]
Electromechanical drive
Maximum 4A/drive
Hydraulic servo-valve
±50mA
with or without lock valve (24V or 48V, maximum 4A)
Motor Power Amplifier MPA
±10mA (with MPA locking signal)
Servo-center transducer
Analog, inductive servo-center transducer
Sensor input
Maximum
±20mA
Preset range 0 to 10mA
Sensor inputs can be calibrated individually
Line Speed
0-10mA
Calibration optionally possible between 0 to 20mA
