TECHNICAL DATA11 - 8
D-MAXE with OI-TS www.maxcessintl.comMI 2-292 1 C
Cable lengths
Standards Modules of the D-MAXE system have been engineered according
to the standards and guidelines of the European Union. A
declaration of conformity is available on file.
Modules of the D-MAXE system are in compliance with the
following standards:
EN 61326-1 Radiated Emissions Class A
Conducted Emissions Class A
FCC 47 CFR Part 15 Class A
ANSI C63.4 Class A
EN 61000-4-2 4kV/8kV
EN 61000-4-3 10V/m
EN 61000-4-4 2kV/1kV
EN 61000-4-5 2kV/1kV
EN 61000-4-6 3Vrms
Connection
Cable lengths
(maximum)
Sensors (except SE-26/-26A) 50m [164 ft]
Sensor SE- 26A 25m [82 ft]
Parallel interface 50m [164 ft]
Servo-center transducer 50m[ 164 ft]
Servo-valves 50m [164 ft]
Locking valve 50m [164 ft]
Drive 14m [46 ft]
RGPC-50 100m [328 ft]
Ethernet 100m [328 ft]
Operator interface 50m [164 ft]
