OPERATING THE CONTROLLER 5 - 7
D-MAXE with OI-TSwww.maxcessintl.com MI 2-292 1 C
Prozessor bedienen.fm
Setup
Menu
∙ Press button 6 in the operator level for
more than 2sec
Menus are available for setting up the parameters of the
selected job or D-MAXE system.
Not all menus are available in the "Servo-center" and
"Automatic" operation modes or in restricted local operation.
Only the menus that can be operated in the current system
status are displayed.
Buttons 2Local Control
3Job
Switch to the Job menu (see page
5-5
)
4 Servo-Center
Switch to the Servo-center transducer menu (see page
5-6
)
5 Hardware
1 Sensors
2 Actuator
3 Digital Inputs
4 Digital Outputs
6 Control
1 Modes
2 Jobs
3 Left/Right buttons
4 Local Control
5 Unit
6 Hardlock
7 Administration
Labels
Serial Number
Backup and Restore
Device Names
8 Network
Maxnet Settings and Distributed System
Customer Settings
To Next Page
