FUSES & CIRCUIT BREAKERS
Article Text (p. 2)
1983 Mazda RX7
For www.iluvmyrx7.com
Copyright © 1998 Mitchell Repair Information Company, LLC
Sunday, August 26, 2001 03:31PM
Fig. 2: Fuse Block Identification (1983-85)
Courtesy of Mazda Motor of America Inc.
1 - Empty
2 - 15 Amp
Horn
3 - 15 Amp
Hazard Warning Lights
4 - 10 Amp
Taillights
5 - 20 Amp
Roof Opener
6 - 10 Amp
Cigarette Lighter
7 - 20 Amp
Radio & Antenna
8 - 15 Amp
Gauges & Back-Up Lights
9 - 20 Amp
Engine
10 - 30 Amp
Power Windows
11 - 20 Amp
Heater Blower
12 - 15 Amp
Rear Defogger
13 - 15 Amp
Windshield Wipers
14 - 10 Amp
Rear Wiper
15 - Empty
16 - Empty
17 - Empty
18 - Empty
19 - 15 Amp
Air Conditioning
20 - Empty
