Proceed as follows to check the coolant level:
1. Position the machine on a flat surface and switch off the engine;
2. Allow the coolant and engine to cool down;
3. Detach the two rubber stay rods (B) securing the bonnet (A).
4. Pull the locking pin (C), raise the bonnet and block it by releasing the pin.
5. Slowly unscrew the radiator cap (D) to the first stop to release the pressure inside the
circuit. When done, remove it.
6. Remove the guard (E) by unscrewing the four screws which hold it in place using a 10-mm
spanner.
7. Place a container under the engine and radiator to collect the used coolant.
8. Unscrew the drain cap (F) from the radiator, with a socket wrench (G) with a 22-mm socket.
9. Drain the coolant from the radiator;
