Table 207. Optional Equipment Electrical Load Analysis Chart, 600N Helicopters (Cont.)
EQUIPMENT
OPTIONS
LANDING EMERGENCY - GENERATOR OUT
DAY
AVG. AMPS.
NIGHT
AVG. AMPS.
DAY
AVG. AMPS.
NIGHT
AVG. AMPS.
5 SEC 2 MIN 15 MIN 5 SEC 2 MIN 15 MIN 5 SEC 2 MIN 15 MIN 5 SEC 2 MIN 15 MIN
GYRO
ATTITUDE 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
DIRECTIONAL 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
CARGO HOOK 15.0 15.0
FLOATS
HEATED PITOT TUBE 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0
ICS KMA24H 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
ADF KR87 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
NAV./COMM. KY155 5.0 5.0 2.0 5.0 5.0 2.0 5.0 5.0 2.0 5.0 5.0 2.0
COMM. KY196A 5.0 5.0 2.0 5.0 5.0 2.0 5.0 5.0 2.0 5.0 5.0 2.0
COMM. KFM965 16.5 16.5 1.5 16.5 16.5 1.5 16.5 16.5 1.5 16.5 16.5 1.5
GPS
KLN90A 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
GARMAN GPS150 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
TRANSPONDER
KT70 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
KT76 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
RADAR ALTIMETER 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
ACTUATOR, YSAS 5.0 5.0 5.0 5.0
INSTALLED OPTIONS - AMPERES
BASIC SHIP AMPERES 21.41 10.71 10.71 41.86 31.11 31.11 19.91 9.21 9.21 23.85 13.11 13.11
TOTAL SHIP AMPERES (NOTE)
NOTE: CONFIGURATION TOTALS SHOULD REFLECT INSTALLED OPTIONS ONLY.
