(30). In engine bay, terminate wire
L522G10N at ground terminal E12
with MS25036-114 terminal.
NOTE: Ground terminal E12 is located in front
of the engine in the center of the bulkhead
on stiffener 369H2523-15.
(31). Thoroughly clean wire harnesses at
lamp housings and clean washers and
inside of conduit nuts with solvent
(CM234).
(32). Apply coating of Dow Corning A-4094
primer to harnesses and inside of
conduit nuts.
(33). Apply adhesive (CM408) to harnesses
at lamp housings, on washers, and
inside conduit nuts. Allow sealant to
cure at room temperature.
(34). After adhesive has cured, assemble
conduit nut and washer on conduit.
(35). Using best route available, route
L522H10 from CB140-1 to:
(a). For 369D; 003 & subs, and 369E;
001-383, terminate at TB101-4 with
MS25036-112 terminal.
(b). For 369E; 384 & subs, 500N; 001 &
subs, and 600N; 003 & subs, attach
wire to bus 2 with MS25036 156
terminal.
NOTE:
D Terminal board TB101 is mounted on un
der side of instrument panel.
D Bus 2 is mounted on the back of the cir
cuit breaker panel.
(36). Terminate wire L522H10 at circuit
breaker switch CB140-1, with
MS25036-156 terminal.
(37). Perform Float Lamp Functional Test.
Table 901. Float Lamp Wire Data List (369D)
Wire No. From Termination To Termination Specification
L522A10 CB140−2 MS25036−156 K307−A1 MS25036−112 M22759/34−10−9, Alt M22759/2−10−9
L522B10 K307−A2 MS25036−112 DS149−1 MS25036−156 M22759/2−10−9, Alt MIL−W−7139
L522C20 K307−X2 MS25036−102 J113−J Solder M22759/34−20−9, Alt M22759/2−20−9
L522D20 S32−1 Solder P113−J Solder M22759/34−20−9, Alt M22759/2−20−9
L522E12 DS149−1 MS25036−156 DS150−1 MS25036−156 M22759/2−12−9, Alt MIL−W−7139
L522F12 DS149−2 MS25036−156 DS150−2 MS25036−156 M22759/2−12−9, Alt MIL−W−7139
L522G10N DS150−2 MS25036−156 E12 MS25036−114 M22759/2−10−9, Alt MIL−W−7139
L522H10 CB140−1 MS25036−156 TB101−4 MS25036−112 M22759/34−10−9, Alt M22759/2−10−9
Jumper K307−A1 MS25036−103 K301−X1 MS25036−102 M22759/34−10−9, Alt M22759/2−10−9
Effectivity: 369D; 003−1149, 1151−1184.
