Table 902. Float Lamp Wire Data List (369D/E)
Wire No. From Termination To Termination Specification
L522A10 CB140−2 MS25036−156 K307−A1 MS25036−112 M22759/34−10−9, Alt M22759/2−10−9
L522B10 K307−A2 MS25036−112 DS149−1 MS25036−156 M22759/2−10−9, Alt MIL−W−7139
L522C20 K307−X2 MS25036−102 J113−J Solder M22759/34−20−9, Alt M22759/2−20−9
L522D20 S32−1 Solder P113−J Solder M22759/34−20−9, Alt M22759/2−20−9
L522E12 DS149−1 MS25036−156 DS150−1 MS25036−156 M22759/2−12−9, Alt MIL−W−7139
L522F12 DS149−2 MS25036−156 DS150−2 MS25036−156 M22759/2−12−9, Alt MIL−W−7139
L522G10N DS150−2 MS25036−156 E12 MS25036−114 M22759/2−10−9, Alt MIL−W−7139
L522H10 CB140−1 MS25036−156 ** MS25036−112 M22759/34−10−9, Alt M22759/2−10−9
Jumper K307−A1 MS25036−103 K301−X1 MS25036−102 M22759/34−10−9, Alt M22759/2−10−9
** 369D − TB101−4
369E − W3
Effectivity: 369D; 1150, 1185 & subs.
369E; 001−383.
Table 903. Float Lamp Wire Data List (369E − 500N)
Wire No. From Termination To Termination Specification
L522A10 CB140−2 MS25036−156 K307−A1 MS25036−112 M22759/34−10−9, Alt M22759/2−10−9
L522B10 K307−A2 MS25036−112 DS149−1 MS25036−156 M22759/2−10−9, Alt MIL−W−7139
L522C22 K307−X2 MS25036−102 J113−K Solder M22759/34−22−9, Alt M22759/2−22−9
L522D22 S32−1 Solder P113−K Solder M22759/34−22−9, Alt M22759/2−22−9
L522E12 DS149−1 MS25036−156 DS150−1 MS25036−156 M22759/2−12−9, Alt MIL−W−7139
L522F12 DS149−2 MS25036−156 DS150−2 MS25036−156 M22759/2−12−9, Alt MIL−W−7139
L522G10N DS150−2 MS25036−156 E12 MS25036−114 M22759/2−10−9, Alt MIL−W−7139
L522H10 CB140−1 MS25036−156 W3 MS25036−156 M22759/34−10−9, Alt M22759/2−10−9
Jumper K307−A1 MS25036−103 K301−X1 MS25036−102 M22759/34−10−9, Alt M22759/2−10−9
Effectivity: 369E; 384 & subs.
500N; 001 & subs.
