Table 904. Float Lamp Wire Data List (600N)
Wire No. From Termination To Termination Specification
L522A10 CB140−2 MS25036−156 K307−A1 MS25036−112 M22759/34−10−9, Alt M22759/2−10−9
L522B10 K307−A2 MS25036−112 DS149−1 MS25036−156 M22759/2−10−9, Alt MIL−W−7139
L522C22 K307−X2 MS25036−102 J113−J Solder M22759/34−22−9, Alt M22759/2−22−9
L522D22 S32−1 Solder P113−J Solder M22759/34−22−9, Alt M22759/2−22−9
L522E12 DS149−1 MS25036−156 DS150−1 MS25036−156 M22759/2−12−9, Alt MIL−W−7139
L522F12 DS149−2 MS25036−156 DS150−2 MS25036−156 M22759/2−12−9, Alt MIL−W−7139
L522G10N DS150−2 MS25036−156 E12 MS25036−114 M22759/2−10−9, Alt MIL−W−7139
L522H10 CB140−1 MS25036−156 W3 MS25036−156 M22759/34−10−9, Alt M22759/2−10−9
Jumper K307−A1 MS25036−103 K301−X1 MS25036−102 M22759/34−10−9, Alt M22759/2−10−9
Effectivity: 600N; 003 & subs.
H. Weight and Balance Data
Weight and balance changes resulting from
installation of the float lamp assembly are
listed in Table 903. After installation of the
float lamp assembly, incorporate changes to
the helicopter weight and balance record as
instructed in CSP-HMI-2.
Table 905. Weight and Balance Data
Weight
lbs (kg)
Arm
in. (cm)
Moment
in.−lb/100 (kgmm/100)
Added +4.8 (+2.177) 115.6 (293.624) 5.55 (63.943)
Removed 0.0 0.0 0.0
Change +4.8 (+2.177) 115.6 (293.624) 5.55 (63.943)
