CSP-HMI-3 MD Helicopters, Inc.
MAINTENANCE MANUAL
[ Main Menu ]
[ HMI−3 Book TOC ]
[ Chapter 97 TOC ]
Page 908
Revision 12
97-02-00
The information disclosed herein is proprietary to MD Helicopters, Inc.
Neither this document nor any part hereof may be reproduced or transferred to
other documents or used or disclosed to others for manufacturing or any other
purpose except as specifically authorized in writing by MD Helicopters, Inc.
Copyright © 1999−2016 by MD Helicopters, Inc.
G97-0208-2
A
A
COMM CONTROL
PANELS
SYSTEM “B”
SYSTEM “A”
RADIO
CONSOLE
SHIPS WIRING
PART OF
369D294373
HARNESS ASSY
AUDIO JUNCTION
BOX
ML PILOT FL
STA
44.65
LOOKING INBOARD
-21
WIRING
HARNESS
K505
RELAY
K500
RELAY
LOOKING DOWN
C ACFT
L
PART OF 369D294373
HARNESS ASSY
INSTRUMENT PANEL
BOTTOM PAN
-11 WIRING HARNESS
NAS1635-02-4 SCREW (4 REQD)
NAS620-2 WASHER (4 REQD)
MS21042L02 NUT (4 REQD)
ROUTE WITH EXISTING SHIPS
WIRING TO TERMINAL BOARDS
MS3367-1-9 STRAPS AS REQD
VIEW A−A
Figure 905. −21 Wiring Harness Routing (Sheet 2 of 2)
