2.6 Instrument Display

1 2

Item Description Item Description

1 Status / Mode 5 Soft key functions

2 Battery indicator 6 Secondary ﬁeld

3 Primary ﬁeld 7 Time

4 Status symbols

Introduction

8 www.megger.com
