14.1.2 Insulation threshold
There are a number options available for Insulation threshold.
1. Select Insulation Threshold, press the tick button ( ).
2. Press soft key 2 and 3 to scroll through the options.
3. Press soft key 4 to accept the selected setting.
4. Press soft key 1 to cancel and return to the previous menu.
14.1.3 Lock
The lock setting enables the lock button for IR tests.
There are two options available for Lock. Press the tick button ( ) to toggle between on and off.
14.1.4 Temperature compensation
1. Select temperature compensation press the tick button ( ).
2. Press soft key 2 and 3 to scroll through the options.
3. Press soft key 4 to accept the selected temperature setting
and move to the motor class setting.
4. Press soft key 2 and 3 to scroll through the options.
5. Press soft key 4 to accept the motor class setting.
6. Press soft key 1 to cancel and return to the previous menu.
14.1.5 Terminal lock out
1. Select Terminal lockout press the tick button ( ).
2. Press soft key 2 and 3 to scroll through the options.
3. Press soft key 4 to accept the selected setting.
4. Press soft key 1 to cancel and return to the previous menu.
Settings
72 www.megger.com
