Meler B4 VS - Optional Equipment; Control Panel

2-5
INTRODUCTION MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL
Optional Equipment
In order to provide the melting equipment with more functions, the following
optional elements may be added:
• Air-tight lid.
• Air drying system for use with PUR adhesives.
• Automatic feeding system.
• Level detector with ligth tower.
• Activation pump mode by external switch (e.g. manual applicator).
Control panel
1. Tank indicator led.
2. Hose indicator led.
3. Applicator indicator led.
4. Temperature set point.
5. Actual temperature.
6. ON/OFF switch.
7. Standby function.
8. Temperatures ok led.
9. Timer programming.
10. Up/Down arrows for element selection.
11. Up/Down arrows for value modification.
1
2
3
4
5
11
8
9
6 7
10
