9-5
SPARE PART LIST MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL
C. MOTOR- PUMP UNIT
Nº Ref. Description
1 150026110 2cc/rev gear pump
1.1 150090410 Pump seating o-rings
1.2 150096570 Seal Ø10+O-ring gear pump set
2 150026090 Motor coupling
3 150129260 Gearmotor Wanshin 3~ACΔ VF-B4 (*)
3 150129230 Kelvin gearmotor B4VS replacement kit (*)
4 150026100 Geared motor support
24
1
1.1 1.2
3
(*) Indicate Reference and serial number of the equipment
