Meler B4 VS - Tank Group

9-3
SPARE PART LIST MA-5082-ENG B4 VS ADHESIVE MELTER MANUAL
A. TANK GROUP
Nº Ref. Description
1 150112110 Complete tank assembly
1.1 150026180 PTFE coated tank
2 150028970 Insulation mantle
3 150112090 Tank port housing
4 150024650 Tank gasket
5 150115280 Tank grid
6 150021790 Plug with o-ring
7 10030007 Current connection strip
8 150114620 Safety thermostat 200°C
9 150022640 Sonde Pt-100
10 150022650 Sonde Ni-120
9
10
7 8
6
1
1.1
3
4
5
2
