Meler Micron + 10 - Control Panel Components

FOCKE MELER GLUING SOLUTIONS
2-4
INTRODUCTION
Control panel components
1. Touch screen.
2. Status central leds (GREEN, YELOW, RED).
3. RED led ‘pumping OFF’.
4. STOP RED Button ‘Start/Stop Pump’.
5. Touch screen ON/OFF button.
6. GREEN led ‘power ON’.
1
2
3
4 5
6
