Meler Micron + 10 - MICRON + Series Range

FOCKE MELER GLUING SOLUTIONS
2-6
INTRODUCTION
MICRON
+
series range
MICRON
+
series
tank capacity -
5: 5kg / 10: 10kg / 20: 20kg / 35: 35kg
no. electric outputs -
2 / 4 / 6
temperature sensor type -
M01: Pt100 / N01: Ni120 / R01: NTC-R
pumping type -
BP: piston
maximum temperature -
200: 200°C / 230: 230°C
pump flow(
1
) -
7: 7cc / 19: 19 cc
automatic feeder (
3
) -
V: w/o / CG: with automatic feeder installed
low level warning light (
5
) -
B0: no warning light / B1: with warning
proportional valve option (
6
) -
VP0: w/o VP / VP1: with VP
Communications -
0B: without / MB: Modbus /
PB:Profibus / PN: Profinet /
EN: Ethernet IP
level sensor (
4
) -
LD0: w/o / LD1: float switch / LD2: capacitive
(1) ‘MICRON+’ 35 only available with 19cc pump
(2) ‘MICRON+’ 35 has not 3x400+T possibility
(3) The automatic feeder is included. The suction tube and hose must be ordered separately.
(4) 230°C units does not allow to use floating level switch
(5) The tower light must be ordered separately
(6) The VP system must be ordered separately
(7) Transformer base included
MICRON+ 5 2 M01 200 BP 7 400N V LD0 B0 VP0 0B
power supply voltaje (
2
) - 400N: 3N~400V 50/60Hz+PE /
230: 1/N~230V 50/60Hz+PE / 400: 3~400V 50Hz+PE (
7
)
