Meler Micron + 10 - Automatic Feeder Operation

FOCKE MELER GLUING SOLUTIONS
4-22
MELTER OPERATION
Use of the automatic feeder
This section presents how to use the automatic feeder. Even if its operation is
very simple, it should not be used by non-trained personnel.
Start up and automatic process
The operation of the vacuum feeder is absolutely automatic and only needs to
switch it on in the program menu, to begin the automatic feeding when the low
level sensor requests it.
The automatic loading process is developed according to the following pattern:
MICRON+ PISTÓN
1 s
60 s
90 s
90 s
ChargeCharge3. Charge
Automatic feeder alarm
Sound on alarm
Over charge time
Charge error alarm
Cover opened alarm
Automatic charge
CHARGE
MICRON+ PISTÓN
1. Heating 2. Settings
3. Charge
4. Statistics
Menu
1
2
3
Low level detection Launching the feeder
Stopping the feeder
System refilled
Detection of the correct level
Start of the over-level timing
