Meler Micron + 10 - Tank Assembly

FOCKE MELER GLUING SOLUTIONS
9-4
SPARE PARTS LIST
A. TANK ASSEMBLY
Nº Ref. Description
1 150113470 Complete tank assembly micron 5 230V
1 150113480 Complete tank assembly micron 10 230V
1 150113490 Complete tank assembly micron 20 230V
1 150114890 Complete tank assembly micron 35 230V
2 150113500 PTFE coated tank micron 5 230V
2 150113510 PTFE coated tank micron 10 230V
2 150113520 PTFE coated tank micron 20 230V
2 150114900 PTFE coated tank micron 35 230V
3 150113370 Tank grid micron 5-10L
3 150114880 Tank grid micron 20L
3 150028830 Tank grid micron 35L
4 150113380 Inlet tank micron 5
4 150113390 Inlet tank micron 10
4 150113400 Inlet tank micron 20
4 150121360 Inlet tank micron 35
5 150113410 Tank insulation mantle micron 5
5 150113420 Tank insulation mantle micron 10
5 150113430 Tank insulation mantle micron 20
5 150114920 Tank insulation mantle micron 35
6 150113440 Insulation mantle inlet tank micron 5
6 150113450 Insulation mantle inlet tank micron 10
6 150113460 Insulation mantle inlet tank micron 20
6 150121370 Insulation mantle inlet tank micron 35
7 10100070 Flat tank filter
7 10100085 Flat tank filter, extra-thick
8 10100071 Tank flat filter mesh
8 10100086 Flat tank filter screen, extra-thick
9 150113270 Drain plug with o-ring
10 150110140 Capacitive sensor (*)
11 150114500 Safety thermostat, up to 200°C
11.1 150114510 Safety thermostat, up to 230°C (*)
12 150130370 Sensor Pt100
12 150130360 Sensor Ni120
12 150123150 Sensor NTC-R
13 150122430 Level detector assembly micron (*)
13.1 150123620 Low level detector (*)
(*) optional
11
11.1
13.1
13
7
8
5
2
6
4
9
12
3
1
10
