FOCKE MELER GLUING SOLUTIONS
9-6
SPARE PARTS LIST
2
3
7
1
4
4
6
5
Nº Ref. Description
1 150113550 7cc pump body with braces and fittings
1 150113560 19cc pump body with braces and fittings
2 10100011 Pump shaft 7cc
2 150023080 Pump shaft 19cc
3 150113570 Tank-pump-distributor seating O-ring kit
4 150113530 7cc pump guide bushing kit
4 150113540 19cc pump guide bushing kit
5 150020590 Short ball and socket joint for pump shaft activator
6 150113580 Pump holding support 7cc
6 150113590 Pump holding support 19cc
7 150024970 Inlet valve fitting micron pump 7cc
7 150024980 Inlet valve fitting micron pump 19cc
C. PUMP ASSEMBLY
